CRBH 7013 A UUCCO crb-crbc series crossed cylindrical roller bearing manufacturers china

  • CRBH 7013 A UUCCO crb-crbc series crossed cylindrical roller bearing manufacturers china
  • CRBH 7013 A UUCCO crb-crbc series crossed cylindrical roller bearing manufacturers china
  • CRBH 7013 A UUCCO crb-crbc series crossed cylindrical roller bearing manufacturers china
  • CRBH 7013 A UUCCO crb-crbc series crossed cylindrical roller bearing manufacturers china
  • CRBH 7013 A UUCCO crb-crbc series crossed cylindrical roller bearing manufacturers china
Place of Origin Luoyang，China
Nombre de la marca YDPB
Certificación ISO
Model Number CRBH 7013 A UUCCO
Minimum Order Quantity 1PCS
Precio 1$
Packaging Details bearing+thin plastic film+waterproof paper+thin foam+carton/wooden cases
Delivery Time 5-7days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 1000pcs/month

Póngase en contacto conmigo para muestras y cupones gratis.

WhatsApp:0086 18588475571

Veloz: 0086 18588475571

Skype: sales10@aixton.com

Si tiene alguna preocupación, ofrecemos ayuda en línea las 24 horas.

x
Datos del producto
Model CRBH 7013 A UUCCO Material GCr15
Structure Crossed Cylindrical Roller bearings Dimension 70x100x13mm
Application Robots arm/machine tool Name Cross-roller bearing
Deja un mensaje
Descripción de producto
CRBH7013 A UUCCO Crossed Roller Bearings (70x100x13mm) Precision Robotic arm use

Crossed Roller Bearings Parameters
Model number- CRBH A 7013UUCCO
Inner ring(mm)- 70
Outer ring(mm)- 100
Width(mm)- 13
Weight(Kg)- 0.38
Materials- GCR15/GCR15SiMn
Precision grade- P5/P4/P2
Lubrication type- Grease lubrication
Rotating part- Inner ring/Outer ring
Load direction- Multi-load
Structure- Integrated Inner/Outer Ring

Series Model No.
CRBH5013A,CRBH6013A,CRBH7013A,CRBH8016A,CRBH9016A,CRBH10020A,CRBH11020A,CRBH12025A,CRBH13025A,CRBH14025A,CRBH15025A,CRBH20025A,CRBH25025A

CRBH series Crossed Roller Bearings Parameters

CRBH 7013 A UUCCO crb-crbc series crossed cylindrical roller bearing manufacturers china 0

shaft diameter Identification number Main dimensious(mm) Mounting dimensions (mm) Basic static load rating Basic static load rating weight
Inner diameter outer diameter width r min da Da C KN Co KN Kg
d D B
50 CRBH 5013A CRBH 5013A UU 50 80 13 0.6 56 74 1.73 2.09 0.29
60 CRBH 6013A CRBH 6013A UU 60 90 13 0.6 66 84 1.88 2.43 0.33
70 CRBH 7013A CRBH 7013A UU 70 100 13 0.6 76 94 2.01 2.77 0.38
80 CRBH 8016A CRBH 8016A UU 80 120 16 0.6 88 112 3.21 4.34 0.74
90 CRBH 9016A CRBH 9016A UU 90 130 16 0.6 98 122 3.31 4.68 0.81
100 CRBH 10020A CRBH 10020A UU 100 150 20 0.6 110 140 5.09 7.22 1.45
110 CRBH 11020A CRBH 11020A UU 110 160 20 0.6 120 150 5.24 7.74 1.56
120 CRBH 12025A CRBH 12025A UU 120 180 25 1 132 168 7.34 10.8 2.62
130 CRBH 13025A CRBH 13025A UU 130 190 25 1 142 178 7.59 11.5 2.82
140 CRBH 14025A CRBH 14025A UU 140 200 25 1 152 188 8.19 13 2.96
150 CRBH 15025A CRBH 15025A UU 150 210 25 1 162 198 8.43 13.8 3.16
200 CRBH 20025A CRBH 20025A UU 200 260 25 1 212 248 9.23 16.9 4
250 CRBH 25025A CRBH 25025A UU 250 310 25 1.5 262 298 10.2 20.7 4.97



Drawings and other parameters ,pls contact us free, thanks



Market:
After years of development ,our products have been sent out to Germany ,Italy, Spain, Romania,Belgium,Israel,Russia,Korea,Mexico,India etc. Good quality and Service earn the constant supports from all our customers. any of your questions will be welcomed here any time.

Payment Terms:
Most of our customers use T/T( 40% in advance, Balance before shippment), Western Union ,Money Gram, for larger amount consider LC, all can be negotiable.


Many other precision bearings series available
